| Model | Diagonal Measurement | Viewing Area （W x H）mm |
Product Height （A）mm |
Black Drop （B3）mm |
Lower Border （B2）mm |
Left/Right （B1）mm |
Product Length （L） |
Endcap Height （Hc）mm |
Endcap Width （Wc） |
| 16:9 | 92" | 2037 x 1146 | 1910.8 | 600 | - | 27 | 2233 | 122.3 | 117.3 |
| 100" | 2214 x 1245 | 2009.8 | 600 | - | 27 | 2410 | 122.3 | 117.3 | |
| 106" | 2347 x 1320 | 2084.8 | 600 | - | 27 | 2543 | 122.3 | 117.3 | |
| 110" | 2435 x 1370 | 2134.8 | 600 | - | 27 | 2631 | 122.3 | 117.3 | |
| 120" | 2656 x 1494 | 2258.8 | 600 | - | 27 | 2852 | 122.3 | 117.3 | |
| 133" | 2944 x 1656 | 2420.8 | 600 | - | 27 | 3160 | 122.3 | 117.3 |
| Model | Diagonal Measurement | Viewing Area （W x H）mm |
Product Height （A）mm |
Black Drop （B3）mm |
Lower Border （B2）mm |
Left/Right （B1）mm |
Product Length （L） |
Endcap Height （Hc）mm |
Endcap Width （Wc） |
16:10 |
92" | 1982 x 1239 | 2003.8 | 600 | - | 27 | 2178 | 122.3 | 117.3 |
| 100" | 2154 x 1346 | 2110.8 | 600 | - | 27 | 2350 | 122.3 | 117.3 | |
| 106" | 2283 x 1427 | 2191.8 | 600 | - | 27 | 2479 | 122.3 | 117.3 | |
| 110" | 2369 x 1481 | 2245.8 | 600 | - | 27 | 2565 | 122.3 | 117.3 | |
| 120" | 2585 x 1615 | 2379.8 | 600 | - | 27 | 2781 | 122.3 | 117.3 | |
| 133" | 2865 x 1790 | 2554.8 | 600 | - | 35 | 3081 | 122.3 | 117.3 |
