| Model | Diagonal Measurement | Viewing Area （W x H）mm | Product Height （A）mm | Black Drop （B3）mm | Lower Border （B2）mm | Left/Right （B1）mm | Product Length （L） | Endcap Height （Hc）mm | Endcap Width （Wc） |
| 1:1 | 84" | 2030x2030 | 2275 | 80 | 40 | 50 | 2216 | 101 | 92 |
| 96" | 2340x2340 | 2585 | 80 | 40 | 47 | 2520 | 101 | 92 | |
| 144" | 3620 x3620 | 3915 | 80 | 40 | 50 | 3813 | 138 | 131 | |
| 150" | 3810 x3810 | 4105 | 80 | 40 | 50 | 4003 | 138 | 131 |
| Model | Diagonal Measurement | Viewing Area （W x H）mm | Product Height （A）mm | Black Drop （B3）mm | Lower Border （B2）mm | Left/Right （B1）mm | Product Length （L） | Endcap Height （Hc）mm | Endcap Width （Wc） |
| 4:3 | 84" | 1710 x 1280 | 1525 | 80 | 40 | 50 | 1896 | 101 | 92 |
| 100" | 2030x1524 | 1769 | 80 | 40 | 50 | 2216 | 101 | 92 | |
| 120" | 2400 x1800 | 2045 | 80 | 40 | 50 | 2586 | 101 | 92 | |
| 130" | 2656 x 1992 | 2268 | 80 | 40 | 50 | 2842 | 119 | 110 | |
| 138" | 2804 x2103 | 2379 | 80 | 40 | 50 | 2990 | 119 | 110 | |
| 145" | 2944 x2208 | 2484 | 80 | 40 | 50 | 3130 | 119 | 110 | |
| 150" | 3048 x 2286 | 2562 | 80 | 40 | 50 | 3234 | 119 | 110 | |
| 165" | 3320 x2490 | 2785 | 80 | 40 | 50 | 3513 | 138 | 131 | |
| 180" | 3620 x2715 | 3010 | 80 | 40 | 50 | 3813 | 138 | 131 | |
| 200" | 4020 x3015 | 3310 | 80 | 40 | 50 | 4213 | 138 | 131 |
| Model | Diagonal Measurement | Viewing Area （W x H）mm | Product Height （A）mm | Black Drop （B3）mm | Lower Border （B2）mm | Left/Right （B1）mm | Product Length （L） | Endcap Height （Hc）mm | Endcap Width （Wc） |
| 16:9 | 92" | 2030 x 1145 | 1960 | 650 | 40 | 50 | 2216 | 101 | 92 |
| 95" | 2103 x 1182 | 1997 | 650 | 40 | 50 | 2289 | 101 | 92 | |
| 100" | 2214 x 1245 | 1960 | 550 | 40 | 50 | 2400 | 101 | 92 | |
| 102" | 2258 x 1269 | 1984 | 550 | 40 | 50 | 2444 | 101 | 92 | |
| 106" | 2340 x 1320 | 1985 | 500 | 40 | 47 | 2520 | 101 | 92 | |
| 120" | 2656 x 1494 | 2090 | 400 | 40 | 50 | 2842 | 119 | 110 | |
| 128" | 2804 x 1577 | 2073 | 300 | 40 | 50 | 2990 | 119 | 110 | |
| 133" | 2944 x 1656 | 2152 | 300 | 40 | 50 | 3130 | 119 | 110 | |
| 138" | 3048 x 1715 | 2211 | 300 | 40 | 50 | 3234 | 119 | 110 | |
| 150" | 3320 x 1867 | 2382 | 300 | 40 | 50 | 3513 | 138 | 131 | |
| 165" | 3620 x 2036 | 2551 | 300 | 40 | 50 | 3813 | 138 | 131 | |
| 180" | 3985 x 2241 | 2756 | 300 | 40 | 50 | 4178 | 138 | 131 |
| Model | Diagonal Measurement | Viewing Area （W x H）mm | Product Height （A）mm | Black Drop （B3）mm | Lower Border （B2）mm | Left/Right （B1）mm | Product Length （L） | Endcap Height （Hc）mm | Endcap Width （Wc） |
| 16:10 | 92" | 1982 x 1239 | 2054 | 650 | 40 | 50 | 2168 | 101 | 92 |
| 100" | 2154 x 1346 | 2061 | 550 | 40 | 50 | 2340 | 101 | 92 | |
| 106" | 2283 x 1427 | 2092 | 500 | 40 | 50 | 2469 | 101 | 92 | |
| 120" | 2656 x1660 | 2256 | 400 | 40 | 50 | 2842 | 119 | 110 | |
| 130" | 2804 x1753 | 2249 | 300 | 40 | 50 | 2990 | 119 | 110 | |
| 133" | 2865 x1790 | 2286 | 300 | 40 | 50 | 3051 | 119 | 110 | |
| 138" | 2944 x1840 | 2336 | 300 | 40 | 50 | 3130 | 119 | 110 | |
| 142" | 3048 x 1905 | 2401 | 300 | 40 | 50 | 3234 | 119 | 110 | |
| 150" | 3231 x 2019 | 2534 | 300 | 40 | 50 | 3424 | 138 | 131 | |
| 180" | 3877 x2423 | 2938 | 300 | 40 | 50 | 4070 | 138 | 131 |
| Model | Diagonal Measurement | Viewing Area （W x H）mm | Product Height （A）mm | Black Drop （B3）mm | Lower Border （B2）mm | Left/Right （B1）mm | Product Length （L） | Endcap Height （Hc）mm | Endcap Width （Wc） |
| 2.35:1 | 80" | 1870 x 796 | 1811 | 850 | 40 | 50 | 2056 | 101 | 92 |
| 92" | 2150 x 915 | 1830 | 750 | 40 | 50 | 2336 | 101 | 92 | |
| 100" | 2337 x 995 | 1810 | 650 | 40 | 50 | 2523 | 101 | 92 |
