| Model | Diagonal Measurement | Viewing Area （W×H）mm |
Product Height （A）mm |
Black Drop （B3）mm |
Lower Border （B2）mm |
Left/Right （B1）mm |
Product Length （L） |
Endcap Height （Hc）mm |
Endcap Width （Wc） |
| 16:9 | 80" | 1777 x 1002 | 1026 | - | - | - | 1801 | 12 | 12 |
| 84" | 1866 x 1052 | 1076 | - | - | - | 1890 | 12 | 12 | |
| 92" | 2043 x 1152 | 1176 | - | - | - | 2067 | 12 | 12 | |
| 96" | 2131 x 1201 | 1225 | - | - | - | 2155 | 12 | 12 | |
| 100" | 2221 x 1251 | 1275 | - | - | - | 2244 | 12 | 12 | |
| 106" | 2353 x 1326 | 1350 | - | - | - | 2377 | 12 | 12 | |
| 110" | 2441 x 1376 | 1400 | - | - | - | 2465 | 12 | 12 | |
| 112" | 2485 x 1401 | 1425 | - | - | - | 2509 | 12 | 12 | |
| 120" | 2663 x 1500 | 1524 | - | - | - | 2687 | 12 | 12 | |
| 133" | 2950 x 1662 | 1686 | - | - | - | 2974 | 12 | 12 | |
| 145" | 3216 x 1812 | 1836 | - | - | - | 3240 | 12 | 12 | |
| 150" | 3327 x 1874 | 1898 | - | - | - | 3351 | 12 | 12 | |
| 16:10 | 80" | 1729 x 1083 | 1107 | - | - | - | 1753 | 12 | 12 |
| 84" | 1815 x 1137 | 1161 | - | - | - | 1839 | 12 | 12 | |
| 92" | 1988 x 1245 | 1269 | - | - | - | 2012 | 12 | 12 | |
| 96" | 2074 x 1298 | 1322 | - | - | - | 2098 | 12 | 12 | |
| 100" | 2160 x 1352 | 1376 | - | - | - | 2184 | 12 | 12 | |
| 106" | 2289 x 1433 | 1457 | - | - | - | 2313 | 12 | 12 | |
| 110" | 2375 x 1487 | 1511 | - | - | - | 2399 | 12 | 12 | |
| 112" | 2418 x 1514 | 1538 | - | - | - | 2442 | 12 | 12 | |
| 120" | 2591 x 1621 | 1645 | - | - | - | 2615 | 12 | 12 | |
| 133" | 2871 x 1796 | 1820 | - | - | - | 2895 | 12 | 12 | |
| 145" | 3129 x 1958 | 1982 | - | - | - | 3135 | 12 | 12 | |
| 150" | 3237 x 2025 | 2049 | - | - | - | 3261 | 12 | 12 |
| Model | Diagonal Measurement | Viewing Area （W×H）mm |
Product Height （A）mm |
Black Drop （B3）mm |
Lower Border （B2）mm |
Left/Right （B1）mm |
Product Length （L） |
Endcap Height （Hc）mm |
Endcap Width （Wc） |
| 16:9 | 80" | 1771 x 996 | 1026 | - | - | - | 1801 | 15 | 15 |
| 84" | 1860 x 1046 | 1076 | - | - | - | 1890 | 15 | 15 | |
| 92" | 2037 x 1146 | 1176 | - | - | - | 2067 | 15 | 15 | |
| 96" | 2125 x 1195 | 1225 | - | - | - | 2155 | 15 | 15 | |
| 100" | 2214 x 1245 | 1275 | - | - | - | 2244 | 15 | 15 | |
| 106" | 2347 x 1320 | 1350 | - | - | - | 2377 | 15 | 15 | |
| 110" | 2435 x 1370 | 1400 | - | - | - | 2465 | 15 | 15 | |
| 112" | 2479 x 1395 | 1425 | - | - | - | 2509 | 15 | 15 | |
| 120" | 2657 x 1494 | 1524 | - | - | - | 2687 | 15 | 15 | |
| 133" | 2944 x 1656 | 1686 | - | - | - | 2974 | 15 | 15 | |
| 145" | 3210 x 1806 | 1836 | - | - | - | 3240 | 15 | 15 | |
| 150" | 3321 x 1868 | 1898 | - | - | - | 3351 | 15 | 15 | |
| 16:10 | 80" | 1723 x 1077 | 1107 | - | - | - | 1753 | 15 | 15 |
| 84" | 1809 x 1131 | 1161 | - | - | - | 1839 | 15 | 15 | |
| 92" | 1982 x 1239 | 1269 | - | - | - | 2012 | 15 | 15 | |
| 96" | 2068 x 1292 | 1322 | - | - | - | 2098 | 15 | 15 | |
| 100" | 2154 x 1346 | 1376 | - | - | - | 2184 | 15 | 15 | |
| 106" | 2283 x 1427 | 1457 | - | - | - | 2313 | 15 | 15 | |
| 110" | 2369 x 1481 | 1511 | - | - | - | 2399 | 15 | 15 | |
| 112" | 2412 x 1508 | 1538 | - | - | - | 2442 | 15 | 15 | |
| 120" | 2585 x 1615 | 1645 | - | - | - | 2615 | 15 | 15 | |
| 133" | 2865 x 1790 | 1820 | - | - | - | 2895 | 15 | 15 | |
| 145" | 3123 x 1952 | 1982 | - | - | - | 3153 | 15 | 15 | |
| 150" | 3231 x 2019 | 2049 | - | - | - | 3261 | 15 | 15 |
