The E-Vision 15000i 4K+ utilizes Texas Instruments (TI) all new 0.8” HEP DMD, which brings a host of exciting features to elevate your viewing experience. Completely redesigned, the new DMD has an increased tilt angle which gives better efficiency and can be used to increase brightness and contrast. The DMD also features new filled via which also reduces the scattering of light that results in increased native contrast. Amongst other improvements, the DMD has been optimised for the colour red to which means that, when coupled with our Colorboost+Red Laser technology, you get reds that were previously unachievable on a 1-Chip DLP projector. All these changes means that the colour space far exceeds REC709, making this one of the most powerful 1-Chip DLP projectors on the market today.
Core Technologies
0.8″ HEP DMD
The E-Vision 15000i 4K+ utilizes Texas Instruments Incorporated (TI) all new 0.8” HEP DMD, which brings a host of exciting features to elevate your viewing experience.
Completely redesigned, the new 0.8” HEP DMD has an increased tilt angle which gives better efficiency and can be used to increase brightness and contrast.
Nexus
Our Next Generation Electronics Platform
Our Next-generation electronics platform has been designed to deliver the most advanced image processing to all projectors. Whichever of our projectors you use, you will be totally familiar with its operation, OSD menu structure and functionality, all of which is seamlessly integrated into our free, Projector Control II software.
IP6x Sealed Optics
The optical system, from the laser light source up to the lens is completely sealed is IP6x rated. This ensures that light output and colour performance will not be degraded due to the ingress of dust. Additionally, this projector is completely filterless as the system is liquid cooled and uses a radiator heat exchanger, minimising maintenance as no replacement or cleaning of filters is necessary and allows unrestricted airflow.
Core Technologies
Highlighting innovative imaging technologies, focusing on advanced laser projection systems that deliver outstanding visual performance for professional and entertainment uses.
Source Redundancy
Source redundancy offers peace of mind for those critical live events. When the main signal is lost, the projector will switch to the backup source to automatically
Flexible Geometry Adjustment
Intuitive adjustment which can be adjusted via PC tool or Remote Controller with a grid on-screen which is synchronized with PC tool
Art-Net Support
Stage controller with Art-Net can directly control the projector (power on/off/brightness adjustment) by network without the need for any DMX to-Net Converter
Intelligent Lens Memory
Intelligent Lens Position Memory which can quickly reset the lens position defined by the user including focus, zoom and lens shift
24/7 operation
The E-vision 15000i 4K+ boasts stable 24/7 operation via efficient heat dissipation and excellent thermal conductivity ensures peak-performance and reliability
Source Redundancy
Features such as source redundancy in the E-Vision 15000i 4K+ offers peace of mind for those critical live events. Whe n the main signal is lost, the projector will switch to the backup source to automatically
MultiAxis Orientation
For maximum flexibility, all E-Vision 16000i Laser projector can be operated in both Portrait and Landscape mode, pointing up and down and every angle in between
Constant Brightness
The E-Vision 15000i 4K+ has an Internal light sensor which keeps constant brightness output when initially operated at lower power
24/7 Operation
Intelligent thermal design ensures stable 24 x 7 operation through efficient heat dissipation and excellent thermal conductivity.
5 year / 20,000 hour warranty in EMEA
Due to the proven reliability and long-term performance of our laser projectors, Digital Projection provides a full 5 years / 20,000 hours warranty.
Built-in Edge Blending
Superbly capable edge blending and multi-projector tiling is provided by way of high bit depth processing that ensures a seamless, contiguous image can be created from multiple projectors.
E-Vision projectors in action
Digital Projection Brings Pompeii to Life in Paris
Created in collaboration with the Pompeii Archaeological Park and Gedeon Programmes, the Réunion des Musées Nationaux – Grand Palais’ Pompeii exhibition has been created to present the historical city before, during and after the dramatic eruption of Mount Vesuvius.
Digital Projection paints a 360° masterpiece with Vincent meets Rembrandt: The Untold Story
Vincent meets Rembrandt: The Untold Story, which opened in 2022, will be captivating visitors until 2027 with this impressive audiovisual spectacle. By seamlessly combining stunning visuals with a compelling audio narration of van Gogh’s letters to his brother Theo, the exhibition reveals the influence Rembrandt had on van Gogh’s artistic journey.
Scaling for fixed aspect ratio screens.16:10 / 16:9 / 4:3 / 2.35:1
Custom warp
Edge Blending
Correction for non-active pixels at the edge of the display.
HDBaseT® Interface
Built in support for transmission of uncompressed High Definition Video over standard CAT5e/6 LAN cable.
Allows the projector to be placed up to 100m from the source with low cost cabling.
HDBaseT® Includes Ethernet 100BaseT and RS232/IR control.
Colour Processing
Powerful seven point colour correction for accurate colour matching.
Projector LAN Control
Free Digital Projection Projector Controller II software
Intuitive user interface for network control.
At-a-glance monitoring of projector status.
Simultaneous control of user-defined groups of projectors.
Source Compatibility
12G-SDI, Supports a high data transfer rate of up to 12 gigabits per second (Gbps), enabling the transmission of uncompressed 4K UHD (Ultra High Definition) video signals with a single connector
Graphics standards up to WUXGA 1920 x 1200 - 120Hz RB, Up to WQXGA 2560 x 1600 60Hz RB (DisplayPort)
Video standards including HDTV 1080p - 60Hz and 4K-UHD (3840 x 2160) 60Hz
Support for up colour gamut up to P3
Inputs/Outputs
Video & Computer
Type
Connector
Qty
HDMI 2.0 (HDCP compatible) DisplayPort 1.2 HDBaseT 12G-SDI in 3G-SDI out
HDMI DisplayPort 8P8C "RJ45" BNC BNC
2 2 1 1 1
.
Communication & Control
Type
Connector
Qty
3D Sync In 3D Sync Out (loop through) 3D Sync Out for IR LAN / Art-Net HDBaseT/Ethernet/RS232/IR Serial In RS-232C Serial Out RS-232C Wired Remote In Wired Remote Out 12V Trigger 12V 350mA USB Power out 5V/2A
BNC BNC BNC EtherCON RJ45 RJ45 9-pin D-Sub 9-pin D-Sub 3.5mm Stereo Jack 3.5mm Stereo Jack 3.5mm Stereo Jack USB Type A
1 1 1 1 1 1 1 1 1 1 1
3D Formats Supported
Off Auto Side by Side Top and Bottom Dual Pipe Frame Sequential
HDTV Formats Supported
EDTV (480p, 576p), HDTV (720p, 1080i, 1080p), 4K-UHD (3840 x 2160), DCI 4K (4096 x 2160)
Computer Compatibility
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, WQXGA
Bandwidth
Remote Control
Infrared/Wired Remote Control Unit
Automation Control
LAN - Webpage control TCP/UDP control RS-232 Alert Mail for Projector LAN Control-Crestron® Connected LAN Control-PJ Link Class 1 compatible LAN Control-AMX® Device Discovery Art-Net (DMX) control
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,
Lens Mount
Centred lens for installation flexability Motorised and programmable shift, zoom and focus. Intelligent Lens Memory with 10 user-definable preset positions (except UST lens).
Mechanical Mounting
Front/Rear Table Front/Rear Ceiling Adjustable Front/Rear Feet Ceiling Mount compatible chassis with 6 off M4*0.7 mounting holes available, Maximum screw length 16mm
Orientation
Table Top or Inverted: Yes Pointing Up: Yes Pointing Down: Yes Roll (Portrait): Yes
Power Requirements
100-240VAC 50/60Hz single phase
Power Consumption
990W (max)
Thermal Dissipation
TBD
Fan Noise
Normal mode: 40 dBA typical Eco Mode: Max 39 dBA
Operating/Storage Temperature Operating:
Operating: 0 to 40 °C (32 to 104 °F) Force ECO over 35°C (95°°F)
Operating Humidity
90% (with maximum temperature of 35°C (95°F)
Weight
29.4 kg / 64.8 lbs
Dimensions
L: 598mm x W: 500mm x H:218mm L: 23.54 inch x W: 19.68 inch x H: 8.58 inch
Safety & EMC Regulations
TBD
