| Model | Diagonal Measurement | Viewing Area （W x H）mm |
Product Height （A）mm |
Black Drop （B3）mm |
Lower Border （B2）mm |
Left/Right （B1）mm |
Product Length （L） |
Endcap Height （Hc）mm |
Endcap Width （Wc） |
| 1:1 | 84" | 2030x2030 | 2335 | 80 | 80 | 50 | 2298 | 145 | 137 |
| 96" | 2340x2340 | 2645 | 80 | 80 | 50 | 2608 | 145 | 137 | |
| 120" | 3048 x3048 | 3353 | 80 | 80 | 50 | 3316 | 145 | 137 | |
| 144" | 3620 x3620 | 3925 | 80 | 80 | 50 | 3894 | 145 | 137 | |
| 150" | 3810 x3810 | 4115 | 80 | 80 | 50 | 4084 | 145 | 137 | |
| 4:3 | 84" | 1710 x1280 | 1529 | 80 | 50 | 50 | 1960 | 103 | 92 |
| 100" | 2030x1524 | 1773 | 80 | 50 | 50 | 2280 | 103 | 92 | |
| 120" | 2400x1800 | 2049 | 80 | 50 | 50 | 2650 | 103 | 137 | |
| 138" | 2804x2103 | 2408 | 80 | 80 | 50 | 3072 | 145 | 137 | |
| 150" | 3048x2286 | 2591 | 80 | 80 | 50 | 3316 | 145 | 137 | |
| 180" | 3620 x2715 | 3020 | 80 | 80 | 50 | 3894 | 145 | 137 | |
| 200" | 4020 x3015 | 3320 | 80 | 80 | 50 | 4294 | 145 | 137 | |
| 16:9 | 92" | 2030 x1145 | 1964 | 650 | 50 | 50 | 2280 | 103 | 92 |
| 95" | 2103 x1182 | 2001 | 650 | 50 | 50 | 2353 | 103 | 92 | |
| 100" | 2214 x 1245 | 1964 | 550 | 50 | 50 | 2464 | 103 | 92 | |
| 102" | 2258 x1269 | 1988 | 550 | 50 | 50 | 2508 | 103 | 92 | |
| 106" | 2340 x1320 | 1989 | 500 | 50 | 47 | 2584 | 103 | 92 | |
| 110" | 2435 x 1369 | 1988 | 450 | 50 | 50 | 2685 | 103 | 92 | |
| 112" | 2479 x1394 | 1963 | 400 | 50 | 50 | 2729 | 103 | 92 | |
| 120" | 2656 x1494 | 2119 | 400 | 80 | 50 | 2924 | 145 | 137 | |
| 133" | 2945 x1656 | 2181 | 300 | 80 | 50 | 3213 | 145 | 137 | |
| 138" | 3048 x1715 | 2240 | 300 | 80 | 50 | 3316 | 145 | 137 | |
| 150" | 3320 x1867 | 2392 | 300 | 80 | 50 | 3594 | 145 | 137 | |
| 180" | 3985 x 2241 | 2766 | 300 | 80 | 50 | 4259 | 145 | 137 | |
| 200" | 4428 x2491 | 3016 | 300 | 80 | 50 | 4702 | 145 | 137 | |
16:10 |
92" | 1982 x 1239 | 2058 | 650 | 50 | 50 | 2232 | 103 | 92 |
| 100" | 2154x1346 | 2065 | 550 | 50 | 50 | 2404 | 103 | 92 | |
| 106" | 2283 x1427 | 2096 | 500 | 50 | 50 | 2533 | 103 | 92 | |
| 120" | 2585 x1615 | 2240 | 400 | 80 | 50 | 2853 | 145 | 137 | |
| 138" | 2972 x1858 | 2383 | 300 | 80 | 50 | 3204 | 145 | 137 | |
| 150" | 3231 x 2019 | 2544 | 300 | 80 | 50 | 3505 | 145 | 137 | |
| 180" | 3877 x 2423 | 2948 | 300 | 80 | 50 | 4151 | 145 | 137 | |
| 200" | 4308 x 2692 | 3217 | 300 | 80 | 50 | 4582 | 145 | 137 | |
2.35:1 |
92" | 2150 x 915 | 1834 | 750 | 50 | 50 | 2400 | 103 | 92 |
| 100" | 2337 x995 | 1814 | 650 | 50 | 50 | 2587 | 103 | 92 | |
| 106" | 2477 x1054 | 1823 | 600 | 50 | 50 | 2727 | 103 | 92 | |
| 120" | 2805 x 1193 | 1918 | 500 | 80 | 50 | 3073 | 145 | 137 | |
| 150" | 3506 x 1492 | 2217 | 500 | 80 | 50 | 3780 | 145 | 137 | |
| 180" | 4207x1790 | 2515 | 500 | 80 | 50 | 4481 | 145 | 137 |
