| Model | Diagonal Measurement | Viewing Area （W×H）mm |
Product Height （A）mm |
Black Drop （B3）mm |
Lower Border （B2）mm |
Left/Right （B1）mm |
Product Length （L） |
Endcap Height （Hc）mm |
Endcap Width （Wc） |
| 1:1 | 84" | 2030 × 2030 | 2252 | 80 | 40 | 50 | 2250 | 79 | 78 |
| 96" | 2334 × 2334 | 2556 | 80 | 40 | 50 | 2554 | 79 | 78 | |
| 4:3 | 84" | 1710 x1280 | 1497 | 80 | 35 | 40 | 1910 | 79 | 78 |
| 90" | 1830 x1372 | 1614 | 80 | 60 | 50 | 2050 | 79 | 78 | |
| 100" | 2030 x1520 | 1762 | 80 | 60 | 50 | 2250 | 79 | 78 | |
| 120" | 2340 x1755 | 1977 | 80 | 40 | 47 | 2554 | 79 | 78 | |
| 133" | 2703 x2027 | 2280 | 80 | 40 | 50 | 2967 | 110 | 110 | |
| 138" | 2811 x2110 | 2363 | 80 | 40 | 50 | 3075 | 110 | 110 | |
| 145" | 2944x2210 | 2463 | 80 | 40 | 50 | 3211 | 110 | 110 | |
| 147" | 2989 x2240 | 2468 | 80 | 40 | 50 | 3211 | 110 | 110 | |
| 16:9 | 84" | 1860 x1046 | 1708 | 500 | 60 | 50 | 2080 | 79 | 78 |
| 92" | 2030 x1145 | 1807 | 500 | 60 | 50 | 2250 | 79 | 78 | |
| 100" | 2214 x1245 | 1887 | 500 | 40 | 50 | 2434 | 79 | 78 | |
| 106" | 2340x1320 | 1962 | 500 | 40 | 47 | 2554 | 79 | 78 | |
| 120" | 2656 x1494 | 2067 | 400 | 40 | 50 | 2967 | 110 | 110 | |
| 122" | 2703 x1519 | 2092 | 400 | 40 | 50 | 3075 | 110 | 110 | |
| 127” | 2811 x1580 | 2053 | 300 | 40 | 50 | 3208 | 110 | 110 | |
| 133" | 2944 x1655 | 2128 | 300 | 40 | 50 | 3253 | 110 | 110 | |
| 135" | 2989 x1681 | 2154 | 300 | 40 | 50 | 3253 | 110 | 110 |
