| Display Technology | DLP™x3, DLP™ Projection System |
| Resolution | 1,920 × 1,200 |
| Brightness Output | 26,000 lm (center)/ 25,000 lm (ANSI) |
| Light Source Type | Red and Blue Laser + ALPD® Laser |
| Life Source Lifetime | 20,000h |
| Contrast | 100,000 : 1 |
| Uniformity | 95% |
| Display Gamut | REC.709 |
| Edge Blending | Horitonal & Vertical EdgeBlending |
| Optional Lenses | 0.7:1, 0.8:1, 0.89-1.29:1, 1.28-1.81:1, 1.6-2.29:1, 2.13-4.16:1, 3.66-5.94:1, 4.5-8.2:1 |
| Screen Size | 70″ ~ 1000″ |
| Keystone | Vertical & horizontal ±20° |
| Refresh Rate | WUXGA 120 fps; 4K decode, 4K 60 fps |
| Band Width | 600MHz |
| Optical Axis Shift | Vertical: ±90%, Horizontal: ±40%, powered |
| I/O | HDMI x 1 / DVI-D x 1 / HDBaseT x 1 / VGA x 1 / DisplayPort x 1 / SDI x 2 /RS-232 (IN & OUT) × 2 / Remote (IN & OUT) × 2 / USB × 1 / RJ-45 × 1 / 3D SYNC (IN & OUT) × 2 / IR 3D out × 1 |
| Power Supply | 100-240V AC, 50/60Hz |
| Power Consumption | Standard: 2500W Stand by: <0.5W |
| Structure Measurements | 32″ x 24″ x 11″ |
| Structure Weight | 150 lbs |
| Noise | 49dB |
| Working Environment Temperature |
32°F~113°F |
| Working Environment Humidity |
20%〜80% (no condensation) |
