Can cover 100″ screen in just 7.8″. Hassle-free installation in small space.
Rich array input/output connection types, including HDMI, DVI 5BNC and others.
| Display Technology | DLP™ x 1, DLP™ Projection System |
| Panel Size | 0.47″ DMD |
| Resolution | 3,840×2160, 4K |
| Brightness Output | 5,000 Im (Standard mode) |
| Light Source Type | ALPD® Laser (Laser type: Class 1) |
| Life Source Lifetime | 20,000h (Standard Mode) |
| Contrast | 100,000 : 1 |
| Uniformity | 85% |
| Display Gamut | REC.709 |
| Lens Throw Ratio | 0.25 : 1 |
| Screen Size | 100″ ~ 150″ (projection distandce 21.65″ ~ 32.68″) |
| Geometric Correction | Vertical keyston: ±40° (auto/manual); horizontal keystone:15° (manual); corner keystone |
| I/O | HDMI × 3 / 3.5mini jack x 2 (in/out) /SPDIF out x 1 / RJ45 x 1 / RS232 x 1 /USB-A x 3 / USB-B x 1 |
| Power Supply | 100-240V AC, 50/60Hz |
| Standard Power Consumption Standard | < 430W |
| Standard Power Consumption Stand by | < 0.5W |
| Orientation | 360° |
| Noise | 36db (Standard) |
| Structure Measurements | 19.1″ × 16.6″ × 6″ |
| Structure Weight | 21.1 lbs |
| Structure Temperature | 32°F〜104°F (95°F〜104°F Eco Mode) |
| Structure Humidity | 20%〜80% (no condensation) |
| Accessories | Power cable x 1 , wireless / wired remote control, software CD-Rom |
