RGB – Primary-colors
Appotronics has creatively applied the RGB primary-colors technology in 1-Chip DLP® system. The RGB 3-segment color wheel system has yield superior picture
performance at 100% color brightness.
CLO=100% CLO=70% CLO=50% CLO=30%
Color Brightness Comparision
Color brightness is a key standard for consumers to evaluate the color performance of their projectors. Lower the color brightness,
lower color reproducing capability a projector will have under the same brightness. The all new S series have 100% color
brightness which surpass all competitors at the same level using similar platforms.
Red Ratio 16%-18%. Higher Saturation.
Most 1-DLP® laser projectors have only a red ratio around 7%. Resulted in gloomy red color reproduction. The S series large
venue machines, based on the patented ALPD® technology, yield over 16% red ratio.
Red Color Ratios=6-7%
TI Color Ratios Recommendation
Coverage Beyond Rec. 709.
Precise Color Rendition. Higher Stability.
Others (Deviated from Rec.709) Appotronis (100% coverage of Rec.709)
‘’Orange red’’ Perfect color reproduction
Higher Flexibility in Installations
Optional Lens
5 optional lens can adapt to all kinds for installation environments. All lens have powered large scale vertical and horizontal shift.
Light Weight Design
All-new light weight design has cut the weight of the system for over 20lbs.
Multiple Color Correction Technology Provides High Uniformity in Edge Blending
Multi-color Correction provides color/brightness uniformity for any blended pictures.
Before correction After correction
Built-in Geometric Correction and Wrapping
Advanced geometric correction enables projection onto spherical, cylindrical and other non-flat surfaces.
Cinema Level Reliability
All-sealed light engine provides complete dust free,filter free structure
All-new patented inner loop color wheel cooling system.
Efficient control over the working temperature of the color wheel and motors provides higher stability and longer life span.
Powerful duo liquid cooling system provides stability even at 104°.
Light source + color wheel duo liquid cooling system provides solid stability even at 104°.
20,000h Proven Lifespan
20,000 hours lifespan proven in mission-critical situations,including digital cinemas and command centers.
Technical Specifications
Display Technology DLP™ x1, DLP™ Projection System
Panel Size 0,67’’ DMD
Resolution 1,920 x 1,200 WUXGA
Brightness Output 15,000 (Center)
Light Source Type ALPD® Laser (Laser type: Class 1)
Life Source Lifetime 20,000h (Standard Mode)
Contrast 100,000 : 1
Uniformity 90%
Display Gamut REC.709
Edge Blending Horitonal & vertical edge blending
Standard Lens 1.23-1.97:1
Optional Lenses 0.62:1, 0.8:1, 1.62-2.96:1, 2.86-4.85:1 4.68-7.96:1
Screen Size 40’’ 〜 600’’
Keystone Vertical/Horizontal ±20°
Optical Axis Shift Vertical ±100%, Horizontal ±40%, powered
Input Resolution 1,920 x 1,200 pixels (higher resolution will be scaled to 1,920 x 1,200 pixels)
I/O DVI x 1 / HDMI x 1 / DP x 1 / VGA x 1 / BNC x 5 / SDI x 1 / 3D SYNC x 2 (in/out) / Wired Remote M3 x 2 (in/out) / HDbaseT X 1
(compatible with RJ45) / RS232 x 2 (in/out) / USB x 1 / IR 3D OUT x 1
Power Supply 100-240V AC, 50/60Hz
Standard Power Consumption 1400W
Stand-by Power Consumption Power saving 0.5W / Stand by 7W
Orientation 360°
Noise 35dB (ECO)/39dB (Standard)
Structure Measurements 24.4’’ x 21’’ x 7’’
Structure Weight 63.7 lbs
Structure Temperature 32°F〜104°F (95°F〜104°F Eco Mode)
Structure Humidity 20%〜80% (no condensation)
Accessories Power cable x 1, wireless/wired remote control unit, remote control, software CD-ROM
1. Based on ISO21118 standard.
2. Dynamic Contrast
3. Not including protruding parts.
4. Including standard lens. Average value.
5. Operation temperature will be set to 32°F〜95°F when working under High Altitude Mode. Output of projector will be reduced
to 50% if ambient temperature exceeds 95°F.
6. The output of the projector will have decreased by approximately 50% around this time. Data from accelerated lab simulations. Actual time may vary
according to the operating modes, environment and other user behaviors.
