Direct control over light source output from projector to achieve faster responding speed
Color brightness is a key indicator to determine the performance of displays. Lower the color
brightness, lower color reproduc- ing capability a projector will have under the same brightness. It
provides an important standard for consumers to evaluate the color performance of their projectors .
The red ratio of most DLP laser projectors stays poorly at around 7%. Resulted in gloomy red color
reproduction. Appotronics installation projectors have over 16% red ratio which exceeds TI’ s standard
of color ratio recommendation.
Appotronics installation projectors maintains precise coverage of Rec 709 while yielding much higher
color brightness compared to competitors.
5 optional lens can adapt to all kinds of installation environments. All lens have powered large scale
vertical and horizontal
shift.
Wide range of powered lens shift (Vertical +100%, Horizontal +40%). Powered lens shift/zoom/focus.
Advanced geometric correction enables projection onto spherical, cylindrical and other non-flat
surfaces.
3D-sync to support infrared 3D and DLP-Link 3D.
All-new light weight design has cut the weight of the system for over 20lbs.
Adjustable driver current on all color segments to insure color uniformity under white field under any
grey level.
Advanced geometric correction enables projection onto spherical, cylindrical and other non-flat
surfaces.
Projector can be oriented in any position, 360° in both horizontal and vertical axes.
Rich array of input/output connection types, including HDMI, DVI, 5BNC and others.
The 1st 200001m DCI ALPD® cinema projector was put in service July 10th, 2014 and has amassed more than 6 years of use since.
Compared to traditional projector lamps. ALPD® laser light source manufacture is completely heavy
metal-free throughout production process, with no waste water and air pollution emitted.
Efficient control over the working temperature of the color wheel and motors provides higher stability
and longer life span.
| Display Technology | DLP™x1, DLP™ Projection System |
| Resolution | 1,920 x 1,200 WUXGA |
| Brightness Output | 7,200 Im |
| Light Source Type | ALPD® Laser (Laser type: Class 1) |
| Life Source Lifetime | 20,000h (Standard Mode) |
| Contrast | 100,000 : 1 |
| Uniformity | 90% |
| Display Gamut | REC.709 |
| Edge Blending | Horitonal & Vertical Edge Blending |
| Standard Lens | 1.23-1.97:1 |
| Optional Lenses | 0.62:1, 0.8:1, 1.62-2.96:1, 2.86-4.85:1 4.68-7.96:1 |
| Screen Size | 40’’ 〜 300’’ |
| Keystone | Vertical/Horizontal ±20° |
| Optical Axis Shift | Vertical ±100%, Horizontal ±40%, powered |
| Input Resolution | 1,920 x 1,200 pixels (higher resolution will be scaled to 1,920 x 1,200 pixels) |
| I/O | DVI x 1 / HDMI x 1 / DP x 1 / VGA x 1 / BNC x 5 / SDI x 1 / 3D SYNC x 2 (in/out) / Wired Remote M3 x 2 (in/out) / HDbaseT X 1 (compatible with RJ45) / RS232 x 2 (in/out) / USB x 1 / IR 3D OUT x 1 |
| Power Supply | 100-240V AC, 50/60Hz |
| Standard Power Consumption | 550W |
| Stand-by Power Consumption | Power saving 0.5W / Stand by 7W |
| Orientation | 360° |
| Noise | 35dB (ECO)/39dB (Standard) |
| Structure Measurements | 17.9″ x 17.9″ x 7″ |
| Structure Weight | 37 lbs |
| Structure Temperature | 32°F〜104°F (95°F〜104°F Eco Mode) |
| Structure Humidity | 20%〜80% (no condensation) |
| Accessories | Power cable x 1, wireless/wired remote control unit, remote control, software CD-ROM |
